PACK F - 10' STARTER BAY
* Toe boards are required if the platform is over 79" high
* Timber scaffold planks can be used to create a toe board
INCLUSIONS:
HS046 EasyRail internal joining spigot 4
230233 Adjustable base plate 4
210420 Alloy EasyRail base frame 2
210422 0.65m alloy EasyRail cantilever bracket 2
HS013 10' standard platform 1
210230 13' Alloy EasyRail truss, roof post 2
210423 10' Alloy EasyRail diagonal brace 1
HS037 10' grasper guardrail 1
210237 EasyRail fixed double coupler 8
PACK G - 24' HANDRAIL
PACK H - 10' ADD ON BAY
* Outriggers must be used every 3 bays minimum
* Diagonals must be used every 4 bays minimum
* 13' x 20' guardrails need to be added every second bay
INCLUSIONS:
HS037 10' grasper guardrail 1
HS013 10' standard platform 1
210230 13' Alloy EasyRail truss, roof post 1
HS046 EasyRail internal joining spigot 2
230233 Adjustable base plate 2
210420 Alloy EasyRail base frame 1
210237 EasyRail fixed double coupler 4
210422 0.65m Alloy EasyRail cantilever bracket 1
PACK I - 8' ADD ON BAY
INCLUSIONS:
HS033 8' grasper guardrail 1
HS007 8' standard platform 1
210230 13' Alloy EasyRail truss, roof post 1
HS046 EasyRail internal joining spigot 2 230233 Adjustable base plate 2
210420 Alloy EasyRail base frame 1
210237 EasyRail fixed double coupler 4
210422 0.65m Alloy EasyRail cantilever bracket 1
PACK J - 21M STRAIGHT PLATFORM EDGE PROTECTION
